Specifications

--------------------------------------------------------------------------------------------------------------------------------

§   Front outlets: 8” Frac Manifold with Master Butterfly valve, 2x 8” Weco Hammer Unions, 2x 4” Camlock outlets with Butterfly valves and 2x 4” Weco outlets with Butterfly valves. Multiple tanks can be manifolded together for large frac jobs.

§   Rear outlets: 1x 4” Weco and 1x 4” Camlock outlets. 4” Drain Line to sump allowing cleaning and sucking dry.

§   1x 4” FMC/Weco style gel/gun line connection with 4” valve in front of tank. Gel line has internal pipe going toward back of tank to each compartment to allow rolling of tank.

§   Integral Jost hydraulic lift cylinders allow raising/lowering of tank. Solar power eliminates need for diesel engine on tank

§   All tank seams double welded (on both sides) and continuous

§   Stairs and platform at front of tank - positioned to allow operator to see inside top roof hatch

§   Sight gauge level indicators at side or front of tank

§   Standard 2” ADR kingpin with 3/8” minimum king pin plate

§   Internal coating Carboline 859 (white or light tan colour). Coating compatible with normal frac fluids.

§   All valves to be FMC/Weco style valves, model 12 or 12N, with PTFE/Viton B seals, and nylon coated gate, and other trim standard. Valve handles with locking detents at 90 degrees included.

Safety Features

--------------------------------------------------------------------------------------------------------------------------------

§   Fully ADR compliant design

§   Stair with extendable handrails

Options

--------------------------------------------------------------------------------------------------------------------------------

§   Dual compartment mobile tanks with separate discharge manifolds and gun lines available

§   Associated hoses and transfer pumps available

§   Open top available
